Features

• Utilizes sensors which emit non-audible sound waves and sense movement. Any movement within the sensor's field-of-view causes a shift in the original emitted frequency. The sensor identifies the change as movement and controls light accordingly. U/S models are immune to external ultrasonic signals from other sources such as white-boards delivering uninterrupted performance.
• Auto-Adapting: Time delay and sensitivity are continually adjusted to occupancy pattern of use
• Configurable for Manual ON/Auto OFF or Auto ON/Auto OFF
• Delayed OFF Timer: The sensor will turn lights OFF if no motion is detected after a specified time
• Exclusive Walk-through Feature: Provides increased energy savings by not leaving the lights ON for an extended period after only momentary occupancy
• Time delay and saved settings are protected during power outages and will return to the last known state
• Output short circuit protection
• Industry-exclusive self-configuring local manual switch input: Momentary or maintained switches are supported
• Presentation Mode feature for slide or film presentations allows push buttons to turn lights OFF and keep them OFF while the room is occupied
• Adjustable Time Delay: 30s, 5min, 10min, 20min, 30min
• Test Mode for simplified commissioning
• Manual Switch and Emergency Override are Class 1 or Class 2 circuits. Class 2 circuits provided for flexibility
• Industry-exclusive “fail-safe” circuitry: In the event of product failure, Return-to-Closed feature causes the relay to default ON which eliminates life safety concerns
• Industry-exclusive H.I.S. (High Inrush Stability) technology designed to handle today's high inrush electronic ballast loads and offer unmatched durability and service
• Robust and reliable mechanically held 10A latching relay provides dependability and robust performance for all load types and provides energy savings over electronically held relays
• Green Visual LED indicator - Blinks during U/S detection and is solid during auto-calibration
• Yellow Visual LED indicator - Blinks during test mode; solid with emergency/BMS input
• Blue Visual LED indicator - Blinks when knob settings are changed and during photocell override
• The Leviton Provolt™ Series combine line voltage occupancy sensors and photocells into a self-contained unit. The integrated design alleviates the need for separate power pack and occupancy sensor wiring making it a low-cost, efficient energy solution for new construction and retrofits. Do you have a question about an occupancy sensor or vacancy sensor? Contact us to learn more.

Specifications

• Country of Origin: China
• RoHS Compliant: False

Product Features

• Application: Code Compliance, Auto ON/Auto OFF, Manual ON/Auto OFF
• Color: White
• Feature: Line Voltage
• Grade: Commercial
• Mounting: Ceiling Mount
• Product Line: Provolt
• Sensor Technology: Ultrasonic (US)
• Sensor Type: Occupancy, Photocell

Performance Specifications

• Coverage (Sq.Ft.): 1000

Electrical Specifications

• Current Consumption: 60-30ma
• Frequency: 50/60Hz
• Load Rating: 120V, 50/60Hz: 8A, Electronic Ballast, 800W/VA, Tungsten, Ballast, 1/4 HP Motor - 230V, 50Hz: 6A/6AX, Electronic Ballast, Magnetic Ballast, Tungsten 1200W/VA, 1/3 HP Motor - 277V, 50/60Hz: 5A, Electronic Ballast, 1200VA, 1/3 HP Motor
• Neutral Wire Connection: Required
• Voltage: 120/230/277 VAC

Standards and Certifications

• Listings: Can be used to comply with ASHRAE 90.1 and Title 24, Part 6 occupancy/vacancy sensing, automatic shut off and daylight harvesting requirements, UL 773A (Occupancy Standard), UL 924 (Emergency Equipment), cUL Listed, CE compliant, NOM Certified, RoHS compliant, NY LLC48 compliant
• Title 24 Compliant: Yes

Mechanical Specifications

• Mounting Type: Ceiling Mount
• Size: Width 4.80" (121.92mm), Depth 2.27" (57.79mm)

Type

• Product Type: Occupancy Sensor and Photocell

Environmental Specifications

• Relative Humidity: 0% to 90% non-condensing
• Storage Temperature Range: -15° to 160°F (-26° to 71°C)

Warranty

• Warranty: 5-Year Limited
