Features

• Up to 3H/2C Heat Pump systems or up to 2H/2C Conventional systems
• Z-Wave Plus certified with improvement in range, battery life, and bandwidth
• Backwards compatibility
• Selectable ranges stops
• Keypad lockout
• DST Enabled
• Time based 7-day, 5-1-1 or 5-2 day programmable, non-programmable, or occupancy controlled with Z-wave panel/app integration
• 5 Year Warranty

Specifications

• Application: Z-wave systems. 24 Vac systems; Gas, Oil, Electric Warm Air; Hot water Coil; Gas, Oil, Electric Hydronic; or Steam / Gravity Systems
• Dimensions (in.): 4-1/16 in. long x 4-1/16 in. wide x 1-3/32 in. deep
• Dimensions (mm): 103.6 mm long x 103.6 mm wide x 28 mm deep
• Includes: Thermostat, UWP mounting system, Installation (J-box) adaptor
• Comments: Compliant with IC Regulations RSS-GEN
• Item Type: Product
• Mounting: UWP Mounting System
• Electrical Ratings: 20 to 30 Vac
• Frequency: 50 Hz; 60 Hz
• Stages: Up to 3 Heat/2 Cool Heat Pumps + Dual fuel; Up to 2 Heat/2 Cool Conventional Systems
• Electrical Connections: Honeywell UWP Mounting System
• Operating Humidity Range (% RH): 5 to 90% RH, non-condensing
• Supply Voltage: 20 to 30 Vac
• Switch Positions (System): HEAT-OFF-COOL-AUTO-EM HEAT
• Switch Positions (Fan): AUTO-ON-CIRC
• Operating Temperature Range (F): 37 F to 102 F
• Operating Temperature Range (C): 2.7 C to 39 C
• Shipping and Storage Temperature Range (F): 20 F to 120 F
• Shipping and Storage Temperature Range (C): 28.9 C to 48.9 C
• Network Communications: Z-wave
• LEDs: LED Back Light
• Power Method: Battery or Hardwired
• Accuracy (C): 0.5 C
• Differential Temperature (F): ± 1 F
• Differential Temperature (C): ± 0.5 C
• Color: White
• Ambient Temperature Range (F): 32 F to 120 F
• Ambient Temperature Range (C): 0 C to 50 C
• Switch Type: Relay
• Programmability: 7 day, 5-1-1 day, 5-2 day, 1 week, Occupancy through Z-wave app, or Non-programmable
• Terminal Designations: RC, R, C, W, W2 - AUX, Y, Y2, O/B, G, K, E, L/A, S, S
• Display: Touchscreen
• Display Size: 6.89 sq. in.
• Temperature Control Mode Selections: Ambient Air Temperature
• Changeover: Heat only
• Setting Temperature Range (F): Heat: 40 F to 90 F
• Setting Temperature Range (C): Heat: 4.5 C to 32.0 C
• Cool Current: 0.02 A to 1.0 A running
• Heat Current: 0.02-1.0 A
• Fan Current: 0.02-.05 A
• External Sensors Available: Optional: Outdoor -- C7089U1006, Remote Indoor — C7189U1005
• Occupancy Sensor: Through Z-wave panel and App
