YBLED60/PCT LED Yardblaster Lighting Solution

The YBLED60/PCT is a high-output LED yardblaster designed for broad-area illumination in demanding outdoor environments. Manufactured by RAB, this fixture is ideal for electrical distributors and lighting solution providers targeting large outdoor areas such as parking lots, corporate parks, and retail settings. It features a rugged die-cast aluminum housing with a durable silver gray finish and a flat polycarbonate lens to withstand harsh conditions while delivering efficient, uniform lighting.

Specifications

• Manufacturer: RAB
• Model Number: YBLED60/PCT
• Lumens: 7,661 lumens
• Efficacy: 136 lumens per watt
• Input Wattage: 56 watts
• Color Temperature: 5000 kelvins (Cool)
• Color Accuracy: 76 CRI (Color Rendering Index)
• Lens Material: Flat Polycarbonate
• Minimum Starting Temperature: -40 degrees Celsius
• Product Weight: 8.6 lbs
• Photocell: Integrated 120-277V Twistlock photocell included
• IP Rating: IP66 for dust and water protection
• Mounting: Wall mount or existing arm/pole (1 5/8" diameter pipe)
• Warranty: 5 years covering light output, color stability, driver performance, and fixture finish

Features

• High-efficiency, long-life surface-mount LEDs with 100,000-hour lifespan
• Wide and uniform Type V distribution pattern for broad area coverage
• Vandal-resistant with high-impact polycarbonate lens
• Rugged die-cast aluminum housing designed for harsh outdoor environments
• Integrated dusk-to-dawn photocell for automatic operation
• Mercury and UV free, RoHS-compliant components supporting green technology
• Surge protection: 4 kV Line-Line, 6 kV Line-Earth
• Color temperature stability with less than 200K shift over 5 years
