Features and Benefits

• Reduced depth of SmartlockPro Slim GFCI makes it easier to install in any electrical box, even shallow ones.
• Terminals allow for easy wiring options – back and side wire capable.
• External back wire clamps provide visual indication of proper wire seating.
• Withstands high torque and resists wire pullout.
• Standard brass self-grounding clip.
• Automatically test the GFCI every time the RESET button is pushed in. The GFCI will not reset if the GFCI circuit is not functioning properly.
• By blocking reset of the GFCI if protection has been compromised, SmartlockPro Slim GFCI reduces the possibility of end-users incorrectly assuming that a reset GFCI outlet is providing ground fault protection when it actually is not.
• A line-load reversal diagnostic feature is provided which prevents the GFCI from being reset and stops power from being fed to the GFCI receptacle face or through to downstream devices. A green LED indicator on the GFCI's face also illuminates to alert the installer to the line-load wiring reversal.
• Trip threshold meets or exceeds UL requirements for tripping time.
• Improved immunity to high-frequency noise reduces nuisance tripping.
• Advanced electronics design provides superior resistance to electrical surges and over-voltages.
• Compatible with all Decora devices and wallplates; available in select Decora colors.
• UL Fed Spec WC-596 rated.

Specifications

AC Horsepower Ratings

• At Rated Voltage: 1 HP

Electrical Specifications

• Dielectric Voltage: Withstands 1250VAC per UL 943 and CSA-C22.2 No. 144.1-06
• Short Circuit Current Rating: 10KA
• Temperature Rise: Max 30C after 100 cycles OL at 150 percent rated current

Environmental Specifications

• Flammability: Rated V-2 per UL94
• Operating Temperature: -35C-+66C

Material Specifications

• Face Material: Thermoplastic
• Body Material: Polycarbonate
• Line Contacts: Brass Double-Wipe .031 Thick
• Terminal Screws: Plated Steel
• Grounding Screw: Plated Steel
• Yoke: Zinc-Plated Steel
• Clamps: Brass
• Notes: w/ Wallplate

Mechanical Specifications

• Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
• Terminal Accom.: 14-10 AWG
• Product ID: Ratings are permanently marked on device

Product Features

• Feature: Tamper-Resistant
• Amperage: 15 Amp
• Voltage: 125 Volt
• NEMA: 5-15R
• Pole: 2
• Wire: 3
• Trip Level: Class A, 5mA plus or minus 1mA
• Termination: Back & Side
• Face Material: Thermoplastic
• Body Material: Polycarbonate
• Grounding: Self-Grounding
• Strap Material: Galvanized Steel
• Color: Brown
• Standards and Certifications: UL/CSA
• Fed Spec WC-596: Yes
• Warranty: 2-Year Limited
• Notes: w/ Wallplate
• Grade: Residential
• Country of Origin: China

Standards and Certifications

• NEMA: WD-6
• ANSI: C-73
• UL498: Yes
• CSA C22.2 No. 42: Yes
• NOM: 057
• UL 943: File E48380
• MIL-SPEC: A-A-55459-SB
• Fed Spec WC-596: Yes
• CSA-C22.2 No. 144.1-06: File LR-57811
