WPLEDFC80/BL LED Wall Pack Lighting Solutions

The WPLEDFC80/BL by RAB is an 80-watt LED wall pack designed for efficient outdoor lighting applications. Suitable for electrical distributors and lighting solution providers, this fixture offers high-performance illumination with a lumen output of 10,043 lumens and an efficacy of 120 lumens per watt. It features a full cutoff design with a tempered glass lens, making it ideal for controlled lighting environments. The product is engineered for durability and reliable operation in ambient temperatures up to 104°F and can start in temperatures as low as -40°C, supporting a wide range of outdoor conditions. Its robust construction and advanced thermal management system ensure longevity and consistent performance, making it a valuable offering for wire and cable, and switchgear suppliers serving commercial and industrial sectors.

Specifications

• Input Wattage: 84 watts
• Lumens: 10,043 lumens
• Efficacy: 120 lumens per watt
• Color Temperature: 5000 kelvins
• Color Accuracy: 72 color rendering index (CRI)
• Lens Material: Tempered Glass
• Ambient Temperature: 104 degrees Fahrenheit
• Minimum Starting Temperature: -40 degrees Celsius
• Product Weight: 17.6 lbs

Features

• Full cutoff (0°) design for precise light control
• Superior thermal management with external "Air-Flow" fins
• Precision die-cast aluminum housing and lens frame for durability
• Weatherproof high-temperature silicone gaskets to seal out moisture
• Two multi-chip, high-output, long-life LEDs with 100,000-hour L70 lifespan
• Maintains 70% of initial lumens at 100,000 hours
• Suitable for wet locations with IP66 ingress protection rating
• Replaces up to 400W metal halide fixtures
• 5-year, no-compromise warranty covering light output, color stability, driver performance, and finish

Downloads & Links

• Spec Sheet
• Instructions
