WPLEDC80YW/BL LED Wall Pack Lighting Solution

The WPLEDC80YW/BL by RAB is an 80-watt LED wall pack designed for reliable, energy-efficient outdoor lighting applications. Ideal for electrical distributors and lighting solutions providers, this fixture offers superior performance with a long lifespan, making it suitable for commercial and industrial environments. It features a durable die-cast aluminum housing with tempered glass lens and advanced thermal management, ensuring consistent light output and color stability under varying ambient temperatures.

Specifications

• Manufacturer: RAB
• Input Wattage: 83 watts
• Lumens: 9,649 lumens
• Efficacy: 116 lumens per watt
• Color Temperature: 3000 kelvins (Warm)
• Color Accuracy: 72 CRI
• Lens Material: Tempered Glass
• Product Weight: 17.6 lbs
• Minimum Starting Temperature: -40¬∞C (-40¬∞F)
• Maximum Ambient Temperature: 40¬∞C (104¬∞F)
• Housing: Precision die-cast aluminum
• Mounting: Die-cast aluminum wall bracket with (5) 1/2" conduit openings and tether for ease of installation
• Cutoff: 7.5 degrees
• Reflector: Specular vacuum metallized polycarbonate
• Gaskets: High-temperature silicone, sealing out moisture
• IP Rating: IP66 for dust and water protection
• Driver: Two Class 2 drivers, 1050mA, 120-277V, 50-60Hz, 0.8A, Power Factor 95%
• Surge Protection: 4kV
• BUG Rating: B1 U1 G1
• Lifespan: 100,000 hours (L70)

Features

• High-performance LED light engine maintaining 70% of initial lumens at 100,000 hours
• Patent-pending thermal management system with external airflow fins for superior heat dissipation
• Weatherproof design with high-temperature silicone gaskets for moisture protection
• Traditional wall pack appearance suitable for retrofit and new installations
• Three cutoff options available, with 7.5¬∞ cutoff on this model
• 5-year no-compromise warranty covering light output, color stability, driver performance, and fixture finish
• Replaces up to 400W metal halide fixtures for energy savings
• Compliant with UL listing for wet locations and DLC qualified for utility rebates
• Mercury and UV free; RoHS-compliant components supporting green technology initiatives
