WPLEDC80W/BL LED Wall Pack Lighting Solution

The WPLEDC80W/BL is a high-performance LED wall pack designed for outdoor lighting applications. Manufactured by RAB, this fixture offers efficient and reliable illumination suitable for commercial and industrial environments. It is ideal for electrical distributors and lighting solution providers seeking durable, energy-saving lighting with superior thermal management and long lifespan. The fixture is compatible with wire and cable installations and meets requirements for wet locations, making it a robust choice for exterior lighting needs. Its bi-level operation supports 50% and 100% output modes, enhancing energy management capabilities.

Specifications

• Manufacturer: RAB
• Model Number: WPLEDC80W/BL
• Input Wattage: 84 watts
• Lumens: 9,815 lumens
• Efficacy: 116 lumens per watt
• Color Temperature: 5000 kelvins (Cool)
• Color Accuracy: 72 CRI
• Lens Material: Tempered Glass
• Ambient Temperature Rating: Up to 104°F (40°C)
• Minimum Starting Temperature: -40°C (-40°F)
• Product Weight: 17.6 lbs
• Housing: Precision die-cast aluminum with lens frame
• Mounting: Die-cast aluminum wall bracket with five 1/2" conduit openings
• Thermal Management: External “Air-Flow” fins for superior heat dissipation
• Ingress Protection: IP66 rated for dust and water
• Driver: Two Class 2 drivers, 1050mA, 120-277V, 50-60Hz, Power Factor 95%
• Surge Protection: 4kV
• BUG Rating: B1 U1 G2
• LED Lifespan: 100,000 hours L70 (maintains 70% initial lumens)

Features

• Bi-level operation with 50% and 100% output modes
• Three cutoff options including 7.5° cutoff for controlled light distribution
• Weatherproof high-temperature silicone gaskets seal out moisture
• Superior thermal management with die-cast aluminum housing and external fins
• Traditional wall pack appearance from the front
• 7-step MacAdam Ellipse binning for consistent color across fixtures
• Color temperature stability with less than 200K shift over 5 years
• RoHS-compliant, mercury and UV free for green technology compliance
• Suitable for wet locations with UL listing and DLC qualification
• 5-year no-compromise warranty covering light output, color stability, driver, and finish
