WPLEDC80NW/BL LED Wall Pack Lighting Solution

The WPLEDC80NW/BL by RAB is an 80-watt LED wall pack designed for commercial and industrial outdoor lighting applications. Suitable for electrical distributors and lighting solutions providers, this fixture offers a high-performance, energy-efficient alternative to traditional metal halide wall packs. It delivers 9,725 lumens at 4000K neutral color temperature with a color rendering index of 76, ensuring accurate color representation. Its durable construction and advanced thermal management system make it ideal for harsh environments and long-term use.

Specifications

• Manufacturer: RAB
• Input Wattage: 82 watts
• Lumens: 9,725 lumens
• Efficacy: 118 lumens per watt
• Color Temperature: 4000 kelvins (Neutral)
• Color Accuracy: 76 CRI
• Lens Material: Tempered Glass
• Ambient Temperature Rating: Up to 104°F (40°C)
• Minimum Starting Temperature: -40°C (-40°F)
• Product Weight: 17.6 lbs
• Driver Type: Constant Current, 120-277V, 50-60Hz
• Surge Protection: 4kV
• Ingress Protection: IP66 for dust and water
• BUG Rating: B1 U1 G1
• Warranty: 5-year no-compromise warranty

Features

• High-performance LED light engine with 100,000-hour L70 lifespan
• Maintains 70% of initial lumens at 100,000 hours
• Superior thermal management with external "Air-Flow" fins
• Precision die-cast aluminum housing with lens frame for durability
• Weatherproof, high-temperature silicone gaskets seal out moisture
• Traditional wall pack appearance from the front
• Three cutoff options including a 7.5° cutoff lens
• Replaces up to 400W metal halide fixtures
• RoHS-compliant, mercury and UV-free components
