Description
WPLED4T78 LED Area Light
The WPLED4T78 by RAB is a high-performance LED area light designed for outdoor lighting applications, suitable for electrical distributors and lighting solutions providers. This fixture offers efficient illumination with a Type IV distribution pattern, ideal for mounting on building sides, walls, and parking lot perimeters. It delivers superior lighting performance while maintaining durability in harsh environments.
Specifications
- Manufacturer: RAB
- Manufacturer Part #: WPLED4T78
- Input Wattage: 77 watts
- Lumens: 10,157 lumens
- Efficacy: 131 lumens per watt
- Color Temperature: 5000 kelvins
- Color Accuracy: 71 CRI
- Ambient Temperature Rating: 104 degrees Fahrenheit (40°C)
- Minimum Starting Temperature: -40 degrees Celsius (-40°F)
- Product Weight: 33.4 lbs
- IP Rating: IP66 (dust and water ingress protection)
- LED Lifespan: 100,000 hours (L70 based on IES LM-80 and TM-21 calculations)
- Driver Type: Constant Current, Class 2, 2000mA, 100-277V, 50-60Hz, Power Factor 99%
- Surge Protection: 6kV
- Equivalent to: 400W Metal Halide
Features
- High-performance LED light engine with six multi-chip, 13W LEDs
- Maintains 70% of initial lumens at 100,000 hours
- Weatherproof with high-temperature silicone gaskets
- Durable die-cast aluminum housing with external fins for superior heat sinking
- Specular vacuum-metallized polycarbonate reflector
- Formulated for long-lasting color and high durability finish
- Conforms to Dark Sky requirements (IDA Fixture Seal of Approval)
- Listed for wet locations as a downlight (UL Listed)
- Design Lights Consortium (DLC) Qualified for utility rebates
- Replaces traditional 400W metal halide fixtures
- 5-Year, No-Compromise Warranty
- Compatible with 100 to 277 Volts operation
