WPLED2T78N/PC2 LED Area Light for Electrical Distributors

The WPLED2T78N/PC2 by RAB is a high-performance LED area light designed for outdoor lighting applications such as walkways, ramps, entrance roadways, and bike paths. This lighting solution is suitable for electrical distributors and lighting solutions providers seeking reliable, energy-efficient fixtures with long lifespans. It features a Type II optic distribution ideal for wide and narrow areas, ensuring uniform illumination. The fixture is built with durable die-cast aluminum housing and weatherproof gaskets, making it suitable for wet locations and harsh outdoor environments.

Specifications

• Manufacturer: RAB
• Input Wattage: 77 watts
• Lumens: 9,220 lumens
• Efficacy: 119 lumens per watt
• Color Temperature: 4000 kelvins (Neutral)
• Color Accuracy: 72 CRI
• Ambient Temperature Rating: 104 degrees Fahrenheit (40°C)
• Minimum Starting Temperature: -40 degrees Celsius (-40°F)
• Weight: 35.0 lbs
• IP Rating: IP66 for dust and water protection
• Driver Type: Constant Current, Class 2, 2000mA, 100-277V, 50-60Hz
• Photocell: 277V button photocell included (compatible with 208V-277V)
• Surge Protection: 6kV
• L70 Lifespan: 100,000 hours
• UL Listed: Suitable for wet locations as a downlight
• DLC Listed: Yes (DLC Product Code: P000017AI)

Features

• Six (6) multi-chip, 13W high-output, long-life LEDs
• Maintains 70% of initial lumens at 100,000 hours
• Weatherproof high-temperature silicone gaskets
• Superior heat sinking with die-cast aluminum housing and external fins
• Specular vacuum-metallized polycarbonate reflector
• 3-step MacAdam Ellipse binning for consistent color uniformity
• Conforms to Dark Sky requirements for reduced light pollution
• Replaces 400W Metal Halide fixtures
• Wide operating voltage range: 100 to 277 Volts
• 5-year no-compromise warranty
• Mercury and UV free; RoHS-compliant components

Downloads & Links

• Spec Sheet
• Instructions
