WPLED2T78N/PC LED Area Light by RAB

The WPLED2T78N/PC is a high-performance LED area light designed for outdoor lighting applications such as walkways, ramps, entrance roadways, bike paths, and other long and narrow areas. This fixture is suitable for electrical distributors and lighting solutions providers requiring reliable, energy-efficient lighting with robust construction. It features a Type II distribution optimized for wide coverage along roadways and smaller side streets, making it an excellent choice for wire and cable installations in outdoor environments. The product is UL listed for wet locations and meets stringent industry standards, ensuring durability and safety for commercial and municipal lighting projects.

Specifications

• Manufacturer: RAB
• Model Number: WPLED2T78N/PC
• Input Wattage: 77 watts
• Lumens: 9,220 lumens
• Efficacy: 119 lumens per watt
• Color Temperature: 4000 kelvins (Neutral)
• Color Accuracy: 72 CRI
• Product Weight: 33.9 lbs
• Ambient Temperature Rating: Up to 104°F (40°C)
• Minimum Starting Temperature: -40°C (-40°F)
• Driver Type: Constant Current, Class 2, 2000mA, 100-277V, 50-60Hz
• Power Factor: 99%
• THD: 4.6% at 120V, 12.9% at 277V
• Surge Protection: 6kV
• IP Rating: IP66 for dust and water ingress
• L70 Lifespan: 100,000 hours
• Finish: Bronze, formulated for high durability and long-lasting color
• Housing: Die-cast aluminum housing, lens frame, and mounting arm
• Reflector: Specular vacuum-metallized polycarbonate
• Photocell: 120V button photocell included (compatible only with 120V)
• Compliance: UL Listed for wet locations, DLC Qualified, Dark Sky Conformance

Features

• High-performance LED light engine with six multi-chip, 13W LEDs
• Maintains 70% of initial lumens at 100,000 hours
• Weatherproof high-temperature silicone gaskets for reliable sealing
• Superior heat sinking with die-cast aluminum housing and external fins
• Replaces 400W metal halide fixtures for energy savings
• Wide Type II optical distribution ideal for roadway and pathway lighting
• 3-step MacAdam Ellipse binning for consistent fixture-to-fixture color
• RoHS-compliant, mercury and UV free components
• 5-year warranty covering light output, color stability, driver performance, and fixture finish
• Compatible with 100 to 277 volts operation
