WPLED2T78 LED Area Light

The WPLED2T78 by RAB is a high-performance LED area light designed for outdoor lighting applications such as wide walkways, entrance roadways, bike paths, and other long, narrow areas. This fixture is suitable for electrical distributors and lighting solutions providers seeking efficient, durable, and weatherproof lighting products. It delivers bright illumination with 9,552 lumens at a color temperature of 5000K, making it ideal for commercial and municipal lighting needs. The unit is built with a die-cast aluminum housing and features a Type II light distribution for optimal area coverage.

Specifications

• Input Wattage: 78 watts
• Lumens: 9,552 lumens
• Efficacy: 122 lumens per watt
• Color Temperature: 5000 kelvins (Cool)
• Color Accuracy: 71 CRI
• Ambient Temperature Rating: 104 degrees Fahrenheit (40°C)
• Minimum Starting Temperature: -40 degrees Celsius (-40°F)
• Weight: 32.5 lbs
• LED Lifespan: 100,000 hours (L70)
• Driver Type: Constant Current, Class 2, 2000mA, 100-277V, 50-60Hz
• Surge Protection: 6kV
• Ingress Protection Rating: IP66 (dust and water resistant)
• Finish: Bronze

Features

• High-performance LED light engine with six multi-chip, 13W, high-output LEDs
• Maintains 70% of initial lumens at 100,000 hours
• Weatherproof high-temperature silicone gaskets ensure durability in harsh environments
• Superior heat sinking with die-cast aluminum housing and external fins for extended fixture life
• Replaces 400W metal halide fixtures for energy savings
• Wide Type II light distribution ideal for larger outdoor areas and roadways
• Compliant with UL listing for wet locations and Design Lights Consortium (DLC) qualified
• Conforms to Dark Sky requirements for reduced light pollution
• 5-year warranty covering light output, color stability, driver performance, and fixture finish
