WP1H50W Wall Pack Lighting Solution

The WP1H50W by RAB is a durable wall pack luminaire designed for outdoor lighting applications, suitable for electrical distributors and lighting solutions providers. It provides efficient illumination with a 50W ED17 lamp, delivering 3400 lumens at an efficacy of 49 lumens per watt. This product is ideal for commercial and industrial exterior lighting needs, ensuring reliable performance in wet locations.

Specifications

• Manufacturer: RAB
• Model Number: WP1H50W
• Lamp Type: ED17
• Input Wattage: 69 watts
• Lamp Wattage: 50 watts
• Lumens: 3400 lumens
• Efficacy: 49 lumens per watt
• Color: White
• Weight: 8.2 lbs
• Dimensions: 8 1/2" W x 8 5/8" H x 7 1/2" D (21.6 cm x 22 cm x 19 cm)
• Ballast Type: HX-NPF 120V
• UL Listed: Suitable for wet locations
• Compliance: EISA 2007 Compliant

Features

• Precision die-cast aluminum housing with durable polyester powder coating
• Easy access conduit openings on top, side, and back for fast internal wiring
• Long life lamp included (10,000 hours)
• Silicone gasket remains in place during relamping for weather tightness
• Cutoff glare shield for reduced light pollution and "friendly" lighting
• Hinged refractor door swings open and remains captive for easy relamping
• Removable semi-specular anodized aluminum reflector for installation and maintenance
• Symmetrical light pattern maximizes spacing between fixtures
• 1/2" NPS tapped conduit openings on top, both sides, and back for conduit or photocontrol

Downloads & Links

• Spec Sheet
