WIREMOLD 4FFCTC15NK 4-INCH FURN FEED COVER ASSY NK
SKU: #409114
Part: #4FFCTC15NK
UPC: 786564085393
WIREMOLD 4FFCTC15NK 4-INCH FURN FEED COVER ASSY NK
SKU: #409114
Part: #4FFCTC15NK
UPC: 786564085393
Description
WIREMOLD 4FFCTC15NK 4-INCH FURN FEED COVER ASSY NK Poke-Thru Device
The WIREMOLD 4FFCTC15NK is a 4-inch diameter furniture feed poke-thru device designed for use in concrete floors with carpet, tile, or wood coverings. It provides conduit entry for electrical and communication wiring, facilitating clean and safe floor penetrations. This device is suitable for electrical distributors, lighting solutions, wire and cable management, and switchgear suppliers requiring reliable floor feed-through solutions compliant with fire resistance standards.
Specifications
- Manufacturer: Wiremold
- Manufacturer Part #: 4FFCTC15NK
- Product Weight: 2.27 lbs
- Cable Entry: Conduit
- Construction: Assembled
- Hole Diameter: Minimum 4" (102mm), Maximum 4 1/8" (105mm)
- Cover Size: 8 1/4" (210mm) diameter
- Conduit Assembly: One 3/4" trade size and one 1 1/2" trade size conduit
- Floor Structure Compatibility: Concrete
- Floor Surface Compatibility: Carpet, Tile, Wood
- Floor Covering Thickness: Minimum 1/8" (3.2mm), Maximum 3/4" (19.1mm)
- UL Fire Classification: 1, 1 1/2, and 2 hours
- UL Scrub Water Protection: TopGuard‚Ñ¢ gasket included
- Maximum Copper Fill: Power – (16) #12 AWG or (10) #10 AWG; Communications – (18) Cat 6/Channel
- Cover Construction: Die-Cast
- Available Finish: Nickel (NK)
Features
- Complete assembly with one-piece finish flange and conduit adapters for power and communication
- Includes scrub water gasket for protection against water ingress; suitable for use on tile, carpet, or wood floors
- Designed for installation in 4" diameter core-drilled holes in concrete floors
- Fire resistance rated for use in reinforced concrete floors with specified thickness and spacing
- Supports separate conduit pathways for power and communications wiring to maintain fire classification
- Compatible with floor coverings up to 3/4" thickness for tile and linoleum, and carpet or wood floors
- Not suitable for use with polished concrete or terrazzo floors
- Conduit fittings required to maintain fire classification and secure wiring
