Winged Twist Connectors Yellow Bagged 500 Bulk Pack – Wire Connectors

The Winged Twist Connectors Yellow Bagged 500 Bulk Pack by Morris Products offers a reliable and efficient solution for electrical wiring connections. Designed for use by electrical distributors and lighting solutions providers, these connectors facilitate easy and secure splicing of wires without the need for pre-twisting. Suitable for wire combinations from 2 #18 up to 3 #12 AWG, they provide excellent electrical insulation and are ideal for wire and cable management in various electrical and lighting applications.

Specifications

• Manufacturer: Morris Products
• Manufacturer Part #: 23184
• Color: Yellow
• Wire Combinations: Max 3 #12, Min 2 #18 AWG
• Dimensions (inches): A: 0.252, B: 0.386, C: 0.717, D: 0.354, E: 1.016
• Pack Quantity: 500
• Product Weight: 0.0090 lbs
• Voltage Rating: 600 Volt, 1000 Volt Max in lighting fixtures and signs
• Temperature Rating: 221°F (105°C) maximum

Features

• Heavy duty thick wall flame retardant thermoplastic shell provides excellent electrical insulation and resists stress and fractures
• Built-in swept-back wing design enables easy tightening without tools, improving torque and reducing labor time
• Live action square wire spring draws wires deep into the spring for a secure grip and reliable connection
• Deep skirt entry protects from flashover and shorts
• No pre-twisting of conductors required; spring creates its own thread
• Reusable connector threads on or off splice for fast and easy circuit changes and additions
• Compact, narrow profile saves space in junction boxes
• Ribbed cap provides secure grip and faster fingertip starts, even with slippery hands

Downloads & Links

• Spec Sheet
