Winged Twist Connectors Blue Bagged 100 Bulk Pack – Wire Connectors

The Winged Twist Connectors Blue Bagged 100 Bulk Pack by Morris Products provides a reliable solution for connecting electrical wiring in various applications. Designed for use by electrical distributors and lighting solutions providers, these connectors facilitate secure and easy wire splicing without the need for pre-twisting. Ideal for wire and cable management, these connectors are suitable for use in switchgear and other electrical installations requiring dependable wire connections.

Specifications

• Manufacturer: Morris Products
• Manufacturer Part #: 23190
• Color: Blue
• Wire Combinations: Max 1 #8 & 3 #10, Min 2 #10 & 1 #12
• Dimensions (inches): A - 0.472, B - 0.740, C - 1.260, D - 0.516, E - 1.575
• Quantity per Bag: 100
• Product Weight: 0.0340 lbs
• UPC: 601986231909

Features

• Heavy duty thick wall flame retardant thermoplastic shell provides excellent electrical insulation and resists stress or fractures.
• Built-in swept-back wing design fits naturally into fingers for increased torque and easy tightening without tools.
• Live action square wire spring draws wires deep into the spring for a secure grip and reliable connection.
• Deep skirt entry offers protection from flashover and shorts.
• No pre-twisting of conductors required; the spring creates its own thread.
• Reusable connector threads on or off splice for fast circuit changes and additions.
• Compact, narrow profile reduces space usage in junction boxes.
• Temperature rated to 221°F (105°C) maximum.
• Rated for 600 Volt, 1000 Volt max in lighting fixtures and signs.
