WhisperSense® DC Fan/LED Light, 50-80-110 CFM - Precision Spot Ventilation

The WhisperSense® DC Fan/LED Light by Panasonic is a precision spot ventilation fan designed for applications such as bathrooms, laundry rooms, mud rooms, basements, and garages. It integrates advanced features including built-in Dual Sensor Technology (motion and moisture) for automatic moisture and odor control, making it suitable for electrical distributors and lighting solutions providers focusing on residential ventilation needs. The fan incorporates Pick-A-Flow™ speed selector to choose airflow rates (50-80-110 CFM) and an ECM motor with SmartFlow® technology to optimize performance under varying static pressure conditions. Its ceiling mount design supports 4 or 6 inch round duct connections and includes an energy-efficient 10W dimmable LED light with a low wattage night light option, compliant with current codes and standards.

Specifications

• Application: Ventilation
• Airflow (CFM): 50, 80, 110 (Pick-A-Flow selectable)
• Mounting: Ceiling Mount
• Duct Size: 4 or 6 IN
• Duct Shape: Round
• Grille Shape: Square
• Grille Dimensions: 13 IN x 13 IN
• Dimensions (WxHxL): 14.17 IN x 16.73 IN x 11.85 IN
• Product Weight: 11.9 lbs
• Lamp Wattage: 10 W (LED)
• Amperage Rating: 0.12-0.18 A
• Frequency Rating: 60 Hz
• Housing Material: Zinc-Aluminum-Magnesium
• Manufacturer Part #: FV-0511VQCL1
• UPC: 885170326392

Features

• Dual Sensor Technology combining motion and moisture sensors for automatic fan operation
• Pick-A-Flow‚Ñ¢ speed selector switch for airflow adjustment (50-80-110 CFM)
• ECM Motor with SmartFlow¬Æ technology automatically adjusts speed to maintain optimal airflow despite static pressure variations
• Energy Star certified LED lighting with 10W dimmable LED chip panel and <1W night light (wired separately)
• Complies with LEED, ENERGY STAR¬Æ, CALGreen, EarthCraft, CA Title 24, and Washington state codes
• Integrated 4" or 6" dual duct adapter for flexible installation options
• UL listed for tub/shower enclosure when GFCI protected
• Auto shut-off feature to minimize energy consumption
• Built-in metal flange serves as an air barrier to reduce leakage during blower door testing
• Built-in damper reduces back drafting
• Single-hinged Flex-Z Fast bracket for flexible, fast, and trouble-free installation, including from below the ceiling
• 6-year warranty on ECM motor, 5 years on LED, 3 years on other parts
