WhisperSense® DC Fan, 50-80-110 CFM Ventilation Fan

The WhisperSense® DC Fan by Panasonic is a precision spot ventilation fan designed for automatic moisture and odor control in residential and commercial applications. Ideal for use in bathrooms, laundry rooms, mud rooms, basements, or garages, this fan integrates advanced Dual Sensor Technology (motion and moisture) for reliable performance. Featuring an enclosed brushless ECM motor with SmartFlow® technology and a Pick-A-Flow™ speed selector switch, it delivers selectable airflow rates of 50, 80, or 110 CFM to meet the latest codes and standards. The fan is suitable for ceiling mounting and offers enhanced energy efficiency and quiet operation, making it a preferred choice for electrical distributors and lighting solutions providers focusing on ventilation and air quality control.

Specifications

• Manufacturer: Panasonic
• Model Number: FV-0511VQC1
• Flow Rate: 50-80-110 CFM
• Application: Ventilation
• Motor Type: Enclosed Brushless ECM Motor
• Amperage Rating: 0.07-0.18 A
• Voltage/Frequency: 120 V / 60 Hz
• Noise Level: Less than 0.3 sones
• Duct Diameter: 4 or 6 inches
• Mounting: Ceiling Mount
• Housing Material: Zinc-Aluminum-Magnesium
• Dimensions (W x H x L): 14.17 in x 16.73 in x 11.85 in
• Product Weight: 11.24 lbs
• UPC: 885170324978

Features

• Dual Sensor Technology with motion and moisture sensors for automatic control of ventilation
• Pick-A-Flow‚Ñ¢ speed selector switch for easy airflow adjustment (50-80-110 CFM)
• ECM Motor with SmartFlow¬Æ technology optimizes airflow and energy efficiency
• Quiet operation with noise levels below 0.3 sones
• UL listed for tub/shower enclosure when GFCI protected
• Built-in damper reduces back drafting and assists with blower door testing
• Integrated 4" or 6" dual duct adapter for flexible installation options
• Complies with LEED, ENERGY STAR¬Æ, CALGreen, EarthCraft, CA Title 24, and Washington state codes
• Durable zinc-aluminum-magnesium housing for long-lasting performance
• Warranty: 6 years on ECM motor, 5 years on LED, 3 years on other parts

Downloads & Links

• FV-0511VQC1 Service Manual (PDF)
• WhisperSense DC Sell Sheet (PDF)
• FV-0511VQC1 Installation Manual (Spanish) (PDF)
• FV-0511VQC1 Installation Manual (English) (PDF)
• FV-0511VQC1 Submittal Sheet (PDF)
• FV-0511VQC1 Architectural Specifications (PDF)
