WhisperGreen® Select Fan, 50-80-110 CFM, Multi-Speed Ventilation Fan

The WhisperGreen® Select Fan by Panasonic is a customizable ceiling mount vent fan designed for whole house indoor air quality (IAQ) solutions. It features multi-speed control with adjustable airflow rates of 50, 80, and 110 CFM, suitable for residential and commercial applications requiring efficient ventilation. This ENERGY STAR® rated fan incorporates advanced brushless ECM motor technology to ensure continuous operation with low noise levels, making it ideal for integration by electrical distributors and lighting solutions providers focusing on wire and cable and switchgear suppliers requiring reliable ventilation components.

Specifications

• Application: Vent fan
• Airflow Capacity: 50-80-110 CFM
• Mounting: Ceiling
• Duct Size: 4 and 6 in (round)
• Grille Shape: Square
• Grille Dimensions: 13 in width x 13 in length
• Product Dimensions: 16.73 in length x 14.17 in width x 11.85 in height
• Product Weight: 11.9 lbs
• Housing Material: 26 gauge Zinc-Aluminum-Magnesium (ZAM) housing
• Finish: White
• Amperage Rating: 0.06-0.10 amps
• Power Rating: 120V / 60Hz
• Energy Efficiency: ENERGY STAR¬Æ certified
• Manufacturer: Panasonic
• Manufacturer Part #: FV-0511VKS2

Features

• Enclosed brushless ECM smart motor technology rated for continuous operation with thermal cutoff fuse
• Adjustable ventilation rates with built-in speed selector and multi-speed control (0, 30-100 CFM in 10 CFM increments)
• Built-in high/low adjustable time delay activated by wall switch or Plug 'N Play‚Ñ¢ modules (Motion Sensor or Condensation Sensor)
• Integrated dual 4" or 6" diameter duct adapter with built-in damper to reduce back draft and assist blower door testing
• Environmentally friendly ZAM coated housing suitable for ceilings insulated up to R60
• Articulating and expandable installation bracket up to 24 inches for flexible mounting
• Grille attaches directly to housing with torsion springs, includes motion sensor cap for optional sensor modules
• UL and cUL listed for tub/shower enclosure when GFCI protected
• RoHS compliant and compliant with ASHRAE 62.2, LEED, California Title-24, WA Ventilation Code, and other IAQ standards
• Plug 'N Play‚Ñ¢ modules provide additional features: Motion Sensor and Condensation Sensor for automatic operation and humidity control
• Low noise operation (<0.3 sones at 0.1 in w.g.) as certified by the Home Ventilating Institute (HVI)

Downloads & Links

• FV-0511VKS2 Submittal (PDF)
• FV-0511VKS2 Architectual Spec (PDF)
• FV-0511VKS2 Installation Manual (English) (PDF)
• WhisperGreen Select Plug and Play Installation Manual (PDF)
• FV-0511VKS2 Service Manual (PDF)
• FV-0511VKS2 Installation Manual (Spanish) (PDF)
• WhisperGreen Sell Sheet (PDF)
• FV-0511VKS2 Installation Manual (French) (PDF)
