WhisperGreen® Select Fan, 110-130-150 CFM Vent Fan

The WhisperGreen® Select Fan by Panasonic is a customizable ceiling mount ventilation fan designed to provide whole-house indoor air quality (IAQ) solutions. It is suitable for use in residential applications requiring efficient ventilation such as bathrooms or other living spaces. This fan offers selectable airflow speeds of 110, 130, or 150 CFM, ensuring flexible ventilation tailored to specific needs. Engineered with energy-saving brushless ECM motor technology, it maintains consistent airflow by automatically adjusting motor speed in response to static pressure, making it an ideal product for electrical distributors and lighting solutions providers focusing on wire and cable or switchgear supply for residential ventilation systems.

Specifications

• Manufacturer: Panasonic
• Model Number: FV-1115VK2
• Application: Vent fan
• Airflow Capacity: 110, 130, 150 CFM (selectable)
• Mounting: Ceiling
• Duct Size: 4 and 6 inches
• Duct Shape: Round
• Grille Shape: Square
• Grille Dimensions: 13 in width x 13 in length
• Housing Material: 26 gauge Zinc-Aluminum-Magnesium (ZAM) housing
• Dimensions (L x W x H): 16.73 in x 14.17 in x 11.85 in
• Weight: 11.8 lbs
• Finish: White
• Current Rating: 0.04 - 0.14 Amperes
• Power Supply: 120 V, 60 Hz
• Energy Star Certified
• UPC: 885170337329

Features

• ENERGY STAR¬Æ rated with built-in speed selector for 110, 130, and 150 CFM airflow options
• Brushless ECM motor engineered for continuous operation with automatic speed adjustment to maintain selected airflow despite static pressure
• Single-hinged Flex-Z Fast‚Ñ¢ bracket for flexible, easy installation between joists
• Dual access junction box simplifies wiring in tight spaces
• Environmentally friendly ZAM housing resists corrosion and enhances durability
• Square grille with elegant design for aesthetic ceiling integration
• Plug 'N Play‚Ñ¢ modules allow for additional features such as multi-speed with time delay, condensation sensor, and motion sensor (sold separately)
• UL and cUL listed for tub/shower enclosure when GFCI protected
• Suitable for ceilings insulated up to R60
• Complies with ASHRAE 62.2, LEED, ENERGY STAR¬Æ IAP, EarthCraft, California Title-24, and Washington Ventilation Code

Downloads & Links

• FV-1115VK2 Architectual Spec (PDF)
• FV-1115VK2 Installation Manual (Spanish) (PDF)
• FV-1115VK2 Submittal (PDF)
• FV-1115VK2 Service Manual (PDF)
• FV-1115VK2 BIM Model (requires Revit Software) (BIM)
• FV-1115VK2 Installation Manual (French) (PDF)
• WhisperGreen Sell Sheet (PDF)
• FV-1115VK2 Installation Manual (English) (PDF)
• WhisperGreen Select Plug and Play Installation Manual (PDF)
