WhisperCeiling® DC Fan|Light 110-130-150 CFM
SKU: #317970
Part: #FV-1115VQL1
UPC: 885170324961
WhisperCeiling® DC Fan|Light 110-130-150 CFM
SKU: #317970
Part: #FV-1115VQL1
UPC: 885170324961
Description
WhisperCeiling® DC Fan|Light 110-130-150 CFM Ventilation Fan
The WhisperCeiling® DC Fan|Light 110-130-150 CFM is a ceiling-mounted ventilation fan designed for energy-efficient air movement and lighting. It features a built-in Pick-A-Flow™ speed selector switch allowing selection of airflow rates at 110, 130, or 150 CFM to meet varying ventilation needs. Equipped with an ECM motor utilizing SmartFlow® technology, this fan automatically adjusts speed to maintain consistent airflow despite duct resistance. The integrated LED lighting unit provides energy-saving illumination equivalent to a standard 40W incandescent lamp, consuming only 10 watts. Ideal for use in residential or commercial ventilation applications, this product supports compliance with current codes and standards. Suitable for electrical distributors and lighting solutions providers focusing on wire and cable and switchgear supplier markets.
Specifications
- Manufacturer: Panasonic
- Manufacturer Part #: FV-1115VQL1
- Application: Ventilation
- Mounting: Ceiling Mount
- Duct Size: 6 IN
- Duct Shape: Round
- Grille Shape: Square
- Grille Dimensions: 13 IN Width x 13 IN Length
- Product Dimensions: 14.17 IN Width x 16.73 IN Height x 11.85 IN Length
- Product Weight: 11.9 lb
- Lamp Wattage: 10 W LED
- Amperage Rating: 0.13-0.21 A
- Frequency Rating: 60 Hz
- Housing Material: Zinc-Aluminum-Magnesium
Features
- Built-in Pick-A-Flow‚Ñ¢ speed selector switch for adjustable airflow (110-130-150 CFM)
- ECM motor with SmartFlow® technology maintains consistent airflow despite duct resistance
- Flex-Z Fast‚Ñ¢ installation bracket for flexible ceiling joist mounting (16" to 24" spacing)
- Energy-efficient LED lighting providing illumination comparable to a 40W incandescent lamp
- Square grille with spring-loaded quick-remove design for easy maintenance
- Complies with latest ventilation codes and standards, including UL listing and HVI certification
- Quiet operation with noise levels under 0.5 sones at maximum airflow
- Compatible with 120V, 60Hz power supply
