WFR6R12830120WS LED Downlight

The WFR6R12830120WS is an energy-efficient LED edge-lit wafer downlight designed for commercial and residential lighting applications. Suitable for electrical distributors and lighting solution providers, this fixture offers consistent illumination with a focus on quality and ease of installation. It operates at 120 volts and delivers 1,003 lumens with an efficacy of 62 lumens per watt, making it a reliable choice for wire and cable integration in lighting systems. The product is manufactured by RAB and is designed to comply with electrical and safety standards.

Specifications

• Input Voltage: 120 volts
• Input Wattage: 12 watts
• Lumens: 1,003 lumens
• Efficacy: 62 lumens per watt
• Color Temperature: 3000 kelvins
• Color Accuracy: 80 color rendering index
• Lens Material: Frosted Polycarbonate Diffusion
• Finish: White
• Product Weight: 1.0000 lb
• Ambient Temperature: 104 degrees fahrenheit
• Minimum Starting Temperature: -22 degrees fahrenheit
• Manufacturer Part #: WFR6R12830120WS

Features

• Edge-lit wafer design for uniform light distribution
• Frosted polycarbonate lens for diffusion and glare reduction
• Compatible with 0-10V dimming circuits
• Compact driver box for easy ceiling installation
• Designed for quick installation with included template and mounting hardware
• Suitable for use in ambient temperatures up to 104°F

Downloads & Links

• Instructions
• Cut Out Template
• Compatibility List
• Spec Sheet
• Energy Star
• Photometrics Report
