Features

• Tight ratcheting mechanism allows precise tensioning with less work and fatigue
• 1-1/2-ton double line, 3/4-ton single line load rating
• Non-conductive dial allows web slack to be adjusted with ease
• Hot rings on hooks, switch and end of handle enable use with hotstick
• 360-degree handle rotation allows for use from any angle
• Meets ANSI/ASME B30.21-2014 and B30.10-2014 standards
• Single line pulling distance is 20-Inches to 138-Inches (50.5 to 350.5 cm)

Warnings

• Read, understand, and follow all warnings, cautions, safety information, and instructions in the manual before operating or servicing this hoist.

Specifications

• Standard: ANSI/ASME B30.21-2014 and B30.10-2014
• Single Line Pulling Distance: 20" to 138" (50.5 to 350.5 cm)
• Double Line Load Rating: 3000 lb (1361 kg)
• Double Line Pulling Distance: 26" to 79" (66.0 to 200.6 cm)
• Single Line Load Rating: 1500 lb (680 kg)
• Included: Hoist; Hot Rings
• Height: 4.2750 in
• Width: 6.7500 in
• Depth: 27.4500 in
• Weight: 13.6000 lbs
