Wattstopper® Time Switch, 7-button Countdown, Lt. Almond - Preset Countdown Time Switch

The Wattstopper® RT-50 Preset Countdown Time Switch is designed to automatically turn lighting or other loads off after a selected on-time expires, providing energy savings in various applications. It replaces standard single-pole wall switches and is suited for use by electrical distributors and lighting solutions providers in controlling wire and cable connected lighting loads. This switch is ideal for closets, utility rooms, pantries, and storage areas where vacancy or occupancy sensors may not be appropriate.

Specifications

• Voltage: 120VAC, 60 Hz (single phase); neutral required
• Load Ratings: 0‚Äì600W incandescent, LED, fluorescent, compact fluorescent (CFL), magnetic low voltage (MLV), electronic low voltage (ELV), and 1/6 Hp motor
• On-time Options: 1, 5, 10, 20, 30, 60 minutes
• Dimensions: 2.63‚Äù x 1.69‚Äù x 1.88‚Äù (67.8 mm x 42.9 mm x 47.8 mm) L x W x D
• Operating Conditions: 32‚Äì131¬∞F (0‚Äì55¬∞C), 95% RH, non-condensing; for indoor use only
• UL and cUL Listed
• Five Year Warranty
• Country of Origin: China

Features

• Seven-button preset time switch with selectable on-times
• Lighted switch for visibility in darkened rooms
• Relay-based switching with zero crossing to reduce relay stress and extend product longevity
• No current leakage to load in off mode for enhanced safety
• Low-profile styling compatible with decorator wall plates
• Operates most common types of lighting loads
