Wattstopper® Time Switch, 7-button Countdown, Ivory - Preset Countdown Time Switch

The Wattstopper RT-50 Preset Countdown Time Switch is designed to automatically turn lighting or other loads off after a selected on-time expires. It replaces standard single-pole wall switches, providing energy savings across a variety of indoor applications such as closets, utility rooms, and storage areas. Suitable for electrical distributors and lighting solutions providers, this time switch supports multiple lighting types and is ideal for wire and cable setups requiring timed control. It is also compatible with decorator wall plates.

Specifications

• Voltage: 120VAC, 60 Hz (single phase); neutral required
• Load Ratings: 0‚Äì600W incandescent, LED, fluorescent, compact fluorescent (CFL), magnetic low voltage (MLV), electronic low voltage (ELV), and 1/6 Hp motor
• On-time options: 1, 5, 10, 20, 30, 60 minutes
• Dimensions (L x W x D): 3.281 in x 1.69 in x 1.88 in (83.3 mm x 42.9 mm x 47.8 mm)
• Operating Conditions: Indoor use only, 32‚Äì131¬∞F (0‚Äì55¬∞C), 95% RH, non-condensing
• UL and cUL listed
• Five year warranty
• Country of Origin: China
• Manufacturer: Pass & Seymour
• Manufacturer Part Number: RT50I

Features

• Seven-button preset time switch with selectable on-times
• Replaces single-pole wall switches for easy retrofit
• Lighted switch for visibility in darkened rooms
• Low-profile styling compatible with decorator wall plates
• Relay-based switching with zero crossing to reduce relay stress and increase longevity
• No current leakage to load in off mode for enhanced safety
• Operates most common types of lighting and small motors
