Wattstopper® Time Switch, 7-button Countdown, Black – Preset Countdown Time Switch

The Wattstopper® RT-50 Preset Countdown Time Switch is designed to automatically turn lighting or other electrical loads off after a selected on-time expires. It replaces standard single-pole wall switches, providing energy savings in various applications. This device is suitable for electrical distributors and lighting solutions providers seeking reliable wire and cable control components or switchgear supplier options for timed lighting control.

Specifications

• Voltage: 120VAC, 60 Hz (single phase); neutral required
• Load Rating: 0‚Äì600W incandescent, LED, fluorescent, compact fluorescent (CFL), magnetic low voltage (MLV), electronic low voltage (ELV), and 1/6 Hp motor
• On-time options: 1, 5, 10, 20, 30, 60 minutes
• Dimensions: 2.63‚Äù x 1.69‚Äù x 1.88‚Äù (Length x Width x Depth)
• Operating Conditions: 32‚Äì131¬∞F (0‚Äì55¬∞C), 95% RH, non-condensing; indoor use only
• UL and cUL listed
• Manufacturer Part #: RT50B
• Country of Origin: China
• Product Weight: 3.3 lbs

Features

• Seven-button preset time switch for easy selection of six preset countdown intervals
• Lighted switch for visibility in darkened rooms
• Replaces standard single-pole switches
• Low-profile styling compatible with decorator wall plates
• Relay-based switching with zero crossing to reduce relay stress and increase longevity
• No current leakage to load in off mode for enhanced safety
• Operates most common types of lighting
• Choice of five decorator colors (black model shown)

Downloads & Links

• Cleaning Instructions for Wiring Devices
• Spec Sheet
• GreenHome, with Help from Watt Stopper, Uses 50% Less Energy than Most Homes"
• #SS-112 Sustainable Packaging Initiative
• RT-50 Preset Countdown Time Switch
• 70-010 - Wiring for Switches RT-50
• RT-50 Preset Countdown Time Switch
