WATTSTOPPER LMSW-101-B Digital Switch 1-Button Black – Low Voltage Lighting Control

The WATTSTOPPER LMSW-101-B is a low voltage digital wall switch designed for manual on/off control of lighting loads within a Digital Lighting Management (DLM) system. It integrates seamlessly with WattStopper room controllers to provide reliable lighting solutions for commercial and institutional applications. This 1-button switch features infrared communication for wireless configuration and status indication, making it suitable for use by electrical distributors and switchgear suppliers seeking efficient wire and cable management in lighting control systems.

Specifications

• Input Voltage: 24 VDC from DLM local network
• Current Consumption: 5 mA
• Power Supply: Wattstopper Room Controller
• Connection to DLM Local Network: 2 RJ-45 ports
• Operating Temperature: 32° to 131°F (0° to 55°C)
• Storage Temperature: 23° to 176°F (-5° to 80°C)
• Relative Humidity: 5 to 95% (non-condensing)
• Indoor Use Only
• Dimensions: 4.1" (104 mm) height × 1.7" (43 mm) width × 1.3" (33 mm) depth
• Product Weight: 0.25 lbs
• UL and cUL Listed
• FCC Part 15 Compliant
• Five Year Warranty

Features

• Single-button low voltage pushbutton switch for on/off lighting control
• Infrared (IR) transceiver for wireless configuration and remote control
• Plug n’ Go™ automatic load assignment simplifies installation
• Push n’ Learn™ technology enables easy button-to-load personalization
• LED status indicator displays load status and button activity
• Sleek, single gang decorator-style device designed for standard electrical boxes
• Compatible with Digital Lighting Management system components using Cat 5e cables and RJ45 connectors
• Meets RoHS material restrictions
• Available in multiple colors; this model is black
• BAA/TAA-compliant models available
