Features

• For use with 50A Twist-Lock® Single Receptacles
• Weatherproof in Open Position with Device Mated

Specifications

• Country of Origin: United States
• Width: 3.300 in
• Each - Width: 3.300 in
• Industry Standard(s): UL Listed - Canadian and U.S.
• Standards - RoHS Compliance Status: CM
• Application: All 50A Twist-Lock®
• Color: Gray
• Knockouts: None
• Number of Outlet: 1-Device
• Shape: Rectangle
• Special Features: Weatherproof in Open Position with Device Mated
• Standard: UL Listed - Canadian and U.S.
• Type: Covers
• Dielectric Strength: Withstands 2,000V minimum
• Number Of Outlets: 1-Device
• Operating Temperature: Maximum continuous 75°C and minimum -40°C without Impact
• Style: For 50A Twist-Lock® Single Receptacle
• Weight: 0.35 lb.
• Class Code: A24
• Description - Invoice: LIFT COVER, POLYCARBONATE, FOR 50A TWIST
• Freight Class Code: 06168002
• Harmonization Code: 3925900000
• Image Actual Or Representative: A
• MSDS Flag: No
• Replaced Catalog Number: 7774WO
• Sub Class Code: A24A290
• Material - Mounting Hardware: Vertical FS/FD Mount- Mounting Screws
• Construction: Molded
• Material: Thermoplastic
• Number of Gang(s): 1-Gang
• Base Unit of Measure: EA
• BOX SIZE: 5.000x20.200x10.100 (in)
• Carton - Gross Weight per Pack: 4.900 lb.
• Carton - Number of Sub Packs: 10
• Carton - Pack Description: Carton
• Carton - SCC-14 Next Lower Level Sub Pack: 783585809526
• Carton - Total Units: 10 EA
• Case Weight: 6.145 lb.
• Each - Pack Description: Each
• Lowest Level UOM: Each
• Pallet Height: 45.000 in
• Pallet Length: 48.000 in
• Pallet Weight: 380.700 lb.
• Pallet Width: 40.000 in

Certifications

• EU RoHS Indicator: Yes
