Features

• Ideal for highly corrosive environments
• Non-Magnetic
• Protective plastic film helps to prevent scratches and damage
• Protective film helps to prevent scratches and damageProvides a plush appearance with the durability of metalBrass and Aluminum are lacquer coated to inhibit oxidation

Specifications

• Country of Origin: Puerto Rico
• Width: 2.740 in
• Each - Width: 2.740 in
• Industry Standard(s): UL Listed
• Size: Standard
• Application: Protection against contact of live terminals and wiring. Provides finished look to installation.
• Cutout: 1) Toggle
• Orientation: Vertical Mount
• Special Features: Protective film helps to prevent scratches and damageProvides a plush appearance with the durability of metalBrass and Aluminum are lacquer coated to inhibit oxidation
• Standard: UL Listed
• Thickness: 0.035
• Type: Toggle
• Display Size: Standard Sized
• Operating Temperature: -40°Cto 85 °C
• Shape: Rectangle
• Style: 1-Toggle
• Description - Invoice: WALL PLATE, 1-G, SWITCH, 430SS
• Freight Class Code: 06168002
• Harmonization Code: 7326190080
• Image Actual Or Representative: A
• MSDS Flag: No
• Material - Mounting Hardware: Screw Mounting
• Construction: Stamped
• Material: Stainless Steel, Type 430
• Number of Gang(s): 1-Gang
• Base Unit of Measure: EA
• BOX SIZE: 3.200x4.900x2.800 (in)
• Carton - Gross Weight per Pack: 1.250 lb.
• Carton - Number of Sub Packs: 10
• Carton - Pack Description: Carton
• Carton - SCC-14 Next Lower Level Sub Pack: 883778095009
• Carton - Total Units: 10 EA
• Case - Total Units: 100 EA
• Case Weight: 3.533 lb.
• Each - Pack Description: Each
• Lowest Level UOM: Each
• Pallet Height: 41.400 in
• Pallet Length: 48.000 in
• Pallet Weight: 1841.400 lb.
• Pallet Width: 40.000 in

Certifications

• EU RoHS Indicator: No
