W34-55L-840 LED Wall Pack Lighting Solutions

The W34-55L-840 is a high-performance LED wall pack designed for outdoor lighting applications, ideal for electrical distributors and lighting solutions providers. Manufactured by RAB, this fixture delivers efficient illumination with a lumen output of 6,577 lumens and an efficacy of 127 lumens per watt, making it suitable for commercial and industrial exterior environments. It operates on a universal voltage range of 120V to 277V at 50/60 Hz, supporting reliable performance in various electrical systems. The fixture features a durable glass lens and is engineered to withstand ambient temperatures up to 104°F, with a minimum starting temperature of -40°C. This product supports 0-10V dimming for enhanced energy control and complies with industry standards for quality and safety.

Specifications

• Manufacturer: RAB
• Model Number: W34-55L-840
• Lumens: 6,577 lumens
• Efficacy: 127 lumens per watt
• Input Wattage: 52 watts
• Color Temperature: 4000 kelvins
• Color Accuracy: 83 CRI (Color Rendering Index)
• Lens Material: Glass
• Operating Ambient Temperature: Up to 104°F
• Minimum Starting Temperature: -40°C
• Power Supply Voltage: 120V-277V, 50/60 Hz
• Product Weight: 9.4 lbs
• UPC: 192552001571

Features

• High lumen output with premium efficacy for energy-efficient lighting
• Durable glass lens suitable for outdoor environments
• Wide operating temperature range supports harsh weather conditions
• Universal voltage driver compatible with multiple supply voltages
• 0-10V dimmable for flexible lighting control
• Designed for easy installation on walls with lens facing downward
• Meets ANSI C82.77 and IES LM-79-2008 photometric standards
• Low total harmonic distortion (THD) ensuring power quality

Downloads & Links

• Instructions
• LM79
• Spec Sheet
