VXBR2SN50 Industrial Wall Mount HID Fixture

The VXBR2SN50 is a durable, die cast aluminum wall-mounted lighting fixture designed for use with 50, 70, and 100 Watt High Pressure Sodium (HPS) and Metal Halide lamps. This fixture is suitable for wet locations and provides low-glare, even light distribution through its clear prismatic glass globe. Ideal for electrical distributors and lighting solution providers, it mounts securely to junction boxes or can be wired inside the housing, making it suitable for commercial and industrial applications requiring reliable wire and cable connections and robust switchgear components.

Specifications

• Manufacturer: RAB
• Model Number: VXBR2SN50
• Input Wattage: 62 watts
• Lumens: 4,000 lumens
• Efficacy: 64 lumens per watt
• Construction Type: Die Cast Aluminum with stainless steel screws
• Weight: 8.2 lbs
• Globe: Clear prismatic, heat resistant glass
• Socket: HID glazed porcelain, 4kv pulse rated with nickel plated screw shell and spring contacts
• Mounting: Wall mount with 1/2" NPS (or 3/4") side and top conduit feed
• Compliance: UL Listed for wet locations, UL Standard 1598

Features

• Weatherproof ballast box
• Die cast aluminum housing for superior durability
• All stainless steel hardware
• Set screw guard retention for secure globe protection
• Clear heat resistant prismatic glass globe standard
• Close-up plugs allow use of Phillips or slotted screwdrivers for easy installation
• High temperature silicone internal gaskets
• Ballast housing mounts to any junction box
