VXBR2F32 Compact Fluorescent Wall Fixture

The VXBR2F32 by RAB Lighting is a compact fluorescent wall-mounted fixture designed for reliable illumination in wet locations. It features a durable die cast aluminum construction with a clear prismatic, heat-resistant glass globe for low glare and even light distribution. This lighting solution is suitable for electrical distributors and lighting professionals requiring robust fixtures compatible with 32-watt compact fluorescent lamps. The fixture mounts easily to junction boxes and supports both side and top conduit feeds, making it versatile for various commercial and industrial applications.

Specifications

• Manufacturer: RAB
• Model Number: VXBR2F32
• Input Wattage: 32 watts
• Lumens: 2,400 lumens
• Efficacy: 75 lumens per watt
• Construction Type: Die Cast Aluminum with stainless steel screws
• Weight: 8.3 lbs
• Compliance: UL Listed for wet locations, UL Standard 1598
• Globe: Clear prismatic, heat resistant glass (standard)
• Ballast: Electric HPF QT type, suitable for 120V, 208V, 240V, and 277V
• Socket: HID glazed porcelain, 4kv pulse rated with nickel plated screw shell and spring contacts
• Ballast Minimum Starting Temperature: 0°F
• Mounting: Wall mount with 1/2" NPS or 3/4" side and top conduit feed

Features

• Weatherproof ballast box for durability in wet environments
• Die cast aluminum housing for superior strength and corrosion resistance
• All stainless steel hardware for long-lasting performance
• One-piece die cast aluminum guard secured with a set screw
• Clear heat resistant prismatic glass globe for even light distribution and low glare
• Close-up plugs compatible with Phillips or slotted screwdrivers for easy installation
• High temperature silicone internal gaskets for effective sealing
• Ballast housing mounts to any standard junction box

Downloads & Links

• Instructions
• Spec Sheet
