VXBR1F26S Compact Fluorescent Wall Fixture

The VXBR1F26S by RAB Lighting is a durable, weatherproof compact fluorescent wall fixture designed for reliable lighting solutions in wet locations. Featuring a die cast aluminum construction, this fixture is suitable for mounting on walls or ceilings with a sturdy bracket and is ideal for electrical distributors and lighting solutions providers requiring robust wire and cable compatible fixtures. It supports 26-watt triple compact fluorescent lamps, delivering 1,800 lumens with high efficacy, making it suitable for commercial and industrial applications where protected, efficient illumination is required.

Specifications

• Manufacturer: RAB
• Model Number: VXBR1F26S
• Input Wattage: 29 watts
• Lumens: 1,800 lumens
• Efficacy: 62 lumens per watt
• Construction Type: Die Cast Aluminum with stainless steel screws
• Weight: 4.1 lbs
• Color: Silver
• Compliance: UL Listed for wet locations, UL Standard 1598
• Socket Type: HID glazed porcelain 4kV pulse rated with nickel plated screw shell and spring contacts; CFL white thermoplastic with integral clips
• Ballast Minimum Starting Temperature: 0°F

Features

• Weatherproof ballast box for outdoor and damp environments
• Clear prismatic heat-resistant glass globe for low glare and even light distribution
• Wall mounting bracket with options for 1/2" NPS or 3/4" side and top conduit feed
• All stainless steel hardware for corrosion resistance
• Set screw guard securely holds the globe in place
• High temperature silicone internal gaskets ensure weatherproof sealing
• Ballast housing mounts directly to any junction box for easy installation

Downloads & Links

• Instructions
• Spec Sheet
