VXBR1F26 Compact Fluorescent Wall Mount Fixture

The VXBR1F26 by RAB Lighting is a durable compact fluorescent wall-mounted fixture designed for commercial and industrial lighting applications. Engineered with die cast aluminum construction and a weatherproof ballast box, this fixture provides efficient, low-glare illumination with a clear prismatic glass globe. It is suitable for wet locations and mounts easily to a junction box or can be wired inside the housing, making it ideal for electrical distributors and lighting solutions providers seeking reliable, robust fixtures for wire and cable installations or switchgear supplier projects.

Specifications

• Manufacturer: RAB
• Model Number: VXBR1F26
• Input Wattage: 29 watts
• Lumens: 1,800 lumens
• Efficacy: 62 lumens per watt
• Product Weight: 7.3 lbs
• Construction Type: Die Cast Aluminum with stainless steel screws
• Globe: Clear prismatic, heat resistant glass (standard)
• Socket: HID glazed porcelain 4kv pulse rated with nickel plated screw shell and spring contacts; CFL white thermoplastic with integral clips
• Ballast Minimum Starting Temperature: 0°F
• UL Listed for wet locations (UL Standard 1598)
• Mounting: Wall mounted with 1/2" NPS (or 3/4") side and top conduit feed

Features

• Weatherproof ballast box for outdoor and wet location use
• Die cast aluminum housing ensures superior durability
• All stainless steel hardware resists corrosion
• Set screw guard securely holds the prismatic glass globe in place
• Clear heat resistant prismatic glass globe provides even, low-glare light distribution
• Close-up plugs allow use of Phillips or slotted screwdrivers for easy installation
• High temperature silicone internal gaskets enhance weatherproofing
• Ballast housing mounts directly to any junction box for flexible installation
• Complies with Buy American Act upon request

Downloads & Links

• Instructions
• Spec Sheet
