VX2SN50B Industrial LED Lighting Fixture

The VX2SN50B is a durable, ceiling-mounted lighting fixture designed for industrial and commercial applications requiring reliable illumination. Manufactured by RAB, this fixture features a cast aluminum housing suited for 50 Watt High Pressure Sodium (HPS) and Metal Halide (MH) lamps, providing even light distribution with low glare through its prismatic globe. It is ideal for electrical distributors and lighting solution providers seeking robust wire and cable compatible fixtures with secure mounting options.

Specifications

• Manufacturer: RAB
• Model Number: VX2SN50B
• Input Wattage: 62 watts
• Lumens: 4,000 lumens
• Efficacy: 64 lumens per watt
• Construction Type: Die Cast Aluminum with stainless steel screws
• Weight: 11.5 lbs
• Color: Black
• Dimensions: 7 ½" diameter x 13 ¼" height (19 cm x 33.6 cm)
• Compliance: UL Listed for wet locations, compliant with UL Standard 1598

Features

• Weatherproof ballast box for reliable operation in wet environments
• Die cast aluminum housing for superior durability and corrosion resistance
• One-piece die cast aluminum guard secured by a set screw
• Clear prismatic heat-resistant glass globe for low glare and even light distribution
• Mounts securely to any junction box with 1/2" NPS or 3/4" side and top conduit feed
• All stainless steel hardware for enhanced longevity
• High temperature silicone internal gaskets for moisture protection
• Close-up plugs compatible with Phillips or slotted screwdrivers for easy installation
• HID glazed porcelain socket rated for 4kV pulse with nickel-plated screw shell and spring contacts
• Suitable for lamp base-up installation only when used outdoors

Downloads & Links

• Spec Sheet
• Instructions
