VX2F42 Compact Fluorescent Lighting Fixture

The VX2F42 by RAB is a durable compact fluorescent lighting fixture designed for ceiling or wall mounting. It features a die cast aluminum housing suitable for 32 and 42 watt compact fluorescent lamps, providing even light distribution with a clear prismatic globe for low glare. This fixture is ideal for electrical distributors and lighting solutions providers seeking reliable, weatherproof lighting with secure installation options for wire and cable connections.

Specifications

• Manufacturer: RAB
• Model Number: VX2F42
• Input Wattage: 46 watts
• Lumens: 3,200 lumens
• Efficacy: 69 lumens per watt
• Construction Type: Die Cast Aluminum
• Weight: 7.5 lbs
• Compliance: UL Listed for wet locations, UL Standard 1598
• Socket Type: CFL White thermoplastic with integral clips
• Ballast Minimum Starting Temperature: 0°F
• Mounting: Ceiling mounted with 1/2" NPS or 3/4" side and top conduit feed

Features

• Weatherproof ballast box
• Die cast aluminum housing and guard for superior durability
• All stainless steel hardware
• Set screw secures guard in place
• Clear heat resistant prismatic glass globe standard
• High temperature silicone internal gaskets
• Ballast housing mounts to any junction box
• Fixture mounts to junction box or can be wired inside housing

Downloads & Links

• Spec Sheet
• Instructions
