VX2F32 Compact Fluorescent Lighting Fixture

The VX2F32 by RAB Lighting is a durable compact fluorescent lighting fixture designed for ceiling or wall mounting. It features a die cast aluminum housing suitable for 32-watt lamps, providing 2,400 lumens with an efficacy of 75 lumens per watt. This fixture is ideal for electrical distributors and lighting solution providers requiring reliable, weatherproof lighting with even light distribution for commercial or industrial applications.

Specifications

• Manufacturer: RAB
• Model Number: VX2F32
• Input Wattage: 32 watts
• Lumens: 2,400 lumens
• Efficacy: 75 lumens per watt
• Construction Type: Die Cast Aluminum with stainless steel screws
• Weight: 4.1 lbs
• Socket: CFL White thermoplastic with integral clips for lamp retention
• Compliance: UL Listed for wet locations, UL Standard 1598
• Ballast: Electronic HPF QT
• Ballast Minimum Starting Temperature: 0°F
• Globe: Clear prismatic, heat resistant glass (white glass and colored/unbreakable Permaglobes available)
• Mounting: Ceiling mounted with 1/2" NPS (or 3/4") side and top conduit feed; mounts to junction box or wired inside housing

Features

• Weatherproof ballast box for wet location suitability
• Die cast aluminum housing for superior durability
• All stainless steel hardware for corrosion resistance
• Set screw guard securely holds protective cage in place
• Clear heat resistant prismatic glass globe for low glare and even light distribution
• Close-up plugs designed for Phillips or slotted screwdrivers ease installation
• High temperature silicone internal gaskets ensure weatherproof sealing
• Ballast housing mounts to any junction box for flexible installation

Downloads & Links

• Instructions
• Spec Sheet
