UNITAP™ UV Black Multiple Tap Connector - Multi Tap Electrical Connector

The UNITAP™ UV Black Multiple Tap Connector is designed for indoor electrical distribution applications, specifically for copper or stranded aluminum conductors. This connector is part of Burndy's UNITAP™ line, providing reliable multi-port tap connections suitable for wire and cable configurations in electrical distribution and lighting solutions. It features a UV-rated black plastisol insulation for durability and protection, supporting 600 V systems and conductor sizes from #14 to 4 AWG.

Specifications

• Application: For Indoor Use Only, Copper Or Stranded Aluminum
• Conductor Size: #14-4 AWG
• Connection Type: Multi Tap
• Insulation Type: Plastisol
• Material: Aluminum
• Width: 1.50 in
• Product Weight: 0.0880 lbs
• Voltage Rating: 600 V
• Ports: 2 (Double Sided Entry)
• Country of Origin: United States
• Made in USA: Yes
• Manufacturer Part #: 1PLD42

Features

• UV Black plastisol cover for insulation and protection
• Double-sided entry design for flexible wiring configurations
• Suitable for copper or stranded aluminum conductors
• 600 Volt rated for standard electrical distribution use
• Compact size with 1.50 inch width for space-efficient installations
• Manufactured in the USA ensuring quality and compliance

Downloads & Links

• Catalog Full Asset Reference 1
• Customer Notices Asset Reference
• Sales Drawing Asset Reference
• Catalog Full Asset Reference 2
• Spec Sheet
