UnderGround Wire Connector, Model 64® Gray/Dk Blue - Underground Wire Connectors

The UnderGround Wire Connector, Model 64® by IDEAL Industries, is designed specifically for harsh underground environments, providing reliable wire connections in below-grade, wet location, and direct burial applications. These connectors are ideal for electrical distributors and lighting solutions requiring secure and moisture-resistant wire connections without the need for heat shrink or corrosion kits. Featuring a tough thermoplastic shell and pre-filled silicone-based sealant, these connectors offer long-lasting protection against moisture and corrosion, making them UL Listed to 486G standards.

Specifications

• Application: Handles wire sizes from #18 to #8 AWG copper. Minimum of 2 #18 AWG. Maximum of 2 #10 AWG.
• Color: Gray
• Product Weight: 0.0341 lbs
• Manufacturer Part #: 30-1264
• UPC: 783250757992

Features

• Pre-filled with silicone-based sealant for moisture and corrosion resistance
• Expanding, live-action spring for fast and secure wire connections
• Tough thermoplastic shell provides extra protection against impacts
• Deep skirt design enhances moisture resistance for below-grade use
• UL Listed to 486G for damp, wet, or direct burial applications
• Eliminates the need for heat shrink, resin packs, and multi-step corrosion kits
• One-use only connection due to pre-filled sealant
• Not suitable for continual submersion applications

Downloads & Links

• UnderGround_WireConnector_SafetySheet.pdf
• UL_Listed_WireCombinations.pdf
• WireConnector_Catalog.pdf
• PDF Misc 3
• UnderGround_WireConnector_Instructions.pdf
• Spec Sheet
• P-2809 WeatherProof_UnderGround WireConnSS.indd
• WireTermination_LimitedWarranty.pdf
