Ultra Grip Connector 20 Amp Industrial Electrical Connector

The Ultra Grip Connector by Cooper Wiring Devices is a 20 amp, 2-pole, 3-wire industrial grade straight blade connector designed for reliable electrical connections in commercial and industrial applications. Constructed with durable nylon housing, this black connector is suitable for use in wiring and lighting solutions, offered by electrical distributors and switchgear suppliers requiring robust and compliant wire and cable connectors.

Specifications

• Amperage: 20 amperes
• Number of Poles: 2
• Number of Wires: 3
• Material: Nylon
• Color: Black
• Manufacturer Part #: AH5369
• UPC: 032664737565
• Product Weight: 0.2300 lbs
• NEMA Configuration: 5-20
• Voltage Rating: 125V/AC
• Wiring Type: Back wire
• Terminal Accommodation: #16 - #12 AWG
• Temperature Rating: -40°C to 75°C (-40°F to 167°F)
• Flammability: UL94 V2 rated

Features

• High impact-resistant thermoplastic nylon housing with easy-grip grooves
• Solid brass plug blades firmly embedded in body for durability and conductivity
• Terminals housed in individual chambers to positively insulate conductors
• Terminal screws are speed-threaded and captive to reduce installation time
• Terminal screws backed out and ready for wiring
• Back-wired clamp type terminals for secure wire connection
• Complies with UL, cULus, Fed Spec, NAFTA, ROHS, and CSA standards
