UGP-20231
SKU: #71592
Part: #UGP-20231
UPC: 783936991955
UGP-20231
SKU: #71592
Part: #UGP-20231
UPC: 783936991955
Description
UGP-20231 Electrical Plug for Hazardous Locations
The Killark UGP-20231 is a 20 Amp, 2-pole, 3-wire plug designed for use in hazardous and wet environments. This electrical plug is suitable for applications in petroleum refineries, chemical plants, grain elevators, feed mills, and other corrosive or damp locations. It is compatible with S, SO, ST, or STO heavy-duty cords and meets NEMA 5-20P configuration with ratings for NEMA 3, 7BCD, and 9FG environments. The plug is constructed from copper-free aluminum alloy, providing corrosion resistance and durability for demanding industrial settings.
Specifications
- Manufacturer: Killark
- Manufacturer Part #: UGP-20231
- Amperage Rating: 20A
- Number of Poles: 2
- Number of Wires: 3
- NEMA Rating: 5-20P; NEMA 3, 7BCD, 9FG
- Cord Type: S, SO, ST, or STO
- Material: Copper-free aluminum (less than 0.4%)
- Dimensions: 6.625 in (Length) x 2.3 in (Width) x 1.875 in (Height)
- Weight: 0.4 lbs
- Country of Origin: China
- Application: Petroleum refineries, chemical plants, wet/damp areas, corrosive environments, grain elevators, feed mills, and indoor/outdoor locations
- Environmental Conditions: Wet and hazardous locations
Features
- Single piece shell design for fewer parts and enhanced durability
- Side tightening terminals accommodate full-sized #2 screwdriver (flat or Phillips)
- Built-in wire strip gauge and wire guides for easy conductor installation
- Insulator fits one way only to ensure correct wiring
- Centered cable grip for secure cord retention
- Copper-free aluminum alloy resists corrosion in harsh environments
- Electrostatically applied and baked powder epoxy/polyester finish for long-lasting protection
- Compatible with explosion-proof and dust-ignition-proof devices from other manufacturers meeting NEMA bladed configurations
- Designed to prevent accidental disengagement with a “turn to engage” locking feature
