U065P Air Conditioner Disconnect – Electrical Disconnect Switch

The U065P Air Conditioner Disconnect by Midwest Electric Products is a non-fusible, single-phase disconnect switch designed for air conditioning applications. It is suitable for use by electrical distributors and switchgear suppliers requiring reliable disconnect solutions for HVAC equipment. This device supports 120/240 Volt AC operation with a current rating of 60 amperes and a horsepower rating of 10 HP. The disconnect features a rugged metallic enclosure with a NEMA 3R weatherproof rating, making it suitable for outdoor installation with surface mounting.

Specifications

• Manufacturer: Midwest Electric Products
• Manufacturer Part #: U065P
• Voltage Rating: 120/240 Volt AC, 1-Phase
• Current Rating: 60 amperes
• Power Rating: 10 HP
• Interrupting Rating: 10,000 AMP
• Enclosure Material: Polyester Powder Coated G90 Galvanized Steel, Metallic
• Enclosure Type: NEMA 3R
• Mounting: Surface
• Dimensions (WxDxH): 5" x 2-1/8" x 7-1/4"
• Cabinet Size: 5" x 7"
• Product Weight: 16 lbs
• Certifications: UL (Canada and US), CUL

Features

• Non-fusible disconnect for user safety during equipment maintenance with removable/reinstallable puller in the OFF position
• Durable metallic enclosure with corrosion-resistant polyester powder coat finish
• NEMA 3R weatherproof rating suitable for outdoor installations
• Designed for surface mounting to ensure easy installation
• Meets National Electric Code requirements for air conditioner disconnects
