Features

• Greater Flexibility - The combination of set screws and NPT threads allows for rigid and intermediate metal conduit as well as electrical metallic tubing applications
• Type LR - Type LR conduit bodies are used for a 90 degree cable pull, with the cable exiting through the right side of the body
• Gasket and Cover - A neoprene gasket and aluminum cover protects your system from dust and water. This conduit body is also listed raintight when used with rigid conduit
• Easy Access - Conduit bodies provide easy access to the interior of conduit systems for pulling, inspection and routine maintenance
• Aluminum Body - Copper-free aluminum conduit bodies reduce the weight of your wiring system while also providing a reliable, cost-effective solution

Certifications and Standards

• UL-514A

Specifications

• Country of Origin: India
• Length: 5.07 in
• Width: 2.28 in
• Height: 1.75 in
• Depth: 1.53 in
• Weight: 45.8 lbs
• BPT Trade Size: 3/4"
• COLOR: Gray
• Field Application: Type LR Combination EMT/Rigid Conduit Body with Cover and Gasket
• FINISH: Enamel paint
• MATERIAL: Aluminum
• UL File #: E11077
• WARRANTY: 1 Year
