Type 2 3-Phase Surge Panel
SKU: #12356
Part: #32277-DY3
UPC: 078477846599
Type 2 3-Phase Surge Panel
SKU: #12356
Part: #32277-DY3
UPC: 078477846599
Next day delivery
Description
Type 2 3-Phase Surge Panel - Surge Protective Device
The Leviton Type 2 3-Phase Surge Panel is designed for surge protection in electrical distribution systems, suitable for 3-phase WYE or Delta configurations at voltages of 277/480V, 220/380V, and 480V. This panel is compatible with Decora Home Control and X10 systems, making it applicable for both residential and commercial electrical distributor environments requiring reliable surge suppression. It provides robust protection against transient voltage surges and is housed in a NEMA 3R enclosure, suitable for outdoor or indoor installation.
Specifications
- Voltage Rating: 277/480V, 220/380V, 480V 3-Phase WYE or Delta
- Frequency: 50 hertz
- Operating Temperature: -10 degrees Celsius
- Flammability Class: Rated V-2 Per UL 94
- UL Listing: UL 1449 4th Edition Type 2
- Manufacturer: Leviton
- Manufacturer Part Number: 32277-DY3
- Country of Origin: Mexico
- Product Weight: 4.5 lbs
Features
- Compatible with Decora Home Control and X10 systems
- Provides surge protection on all phases for 3-phase electrical systems
- Hybrid component suppression design for enhanced transient suppression
- Audible and visual failure indicators for diagnostic monitoring
- Includes remote monitoring dry contacts for status indication
- Convenient surface mounting with 3/4 inch conduit knockout
- NEMA 3R enclosure for environmental protection
