Features

• Sizing - For use with 1/2" flexible metal conduit, AC or HCF cable when installing into a 1/2" knockout
• Two-Screw Strap - Use the 2-way Phillips/slotted head screws to tighten down strap and secure conduit or cable in place
• Zinc Body - Die cast zinc connectors have a precise fit and finish for a trouble-free performance and excellent corrosion resistance when used in harsh environments
• Safety Compliance - Bridgeport strap connectors are UL listed and RoHS compliant

Certifications and Standards

• UL-514B

Specifications

• Country of Origin: United States
• Length: 1.75 in
• Width: 1.375 in
• Depth: 1.125 in
• Weight: 11.9 lbs
• BPT Trade Size: 1/2"
• Field Application: Recommended cable types used to connect armored cable to 1/2" K.O. in box or enclosure. 8/2 - 6/4 AC (.675"-.90" diameter) and 1/2" FMC For AC/FMC, Use Anti-Short Bushing Cat. #1003 For Teck90, Dry Location Only 10/3 - 8/3 (.68" to .85")
• FINISH: Ball burnished, mirror smooth
• MATERIAL: Zinc Die Cast
• UL File #: E20534
