TradeSelect Toggle Switch Three Way - Residential Toggle Switches

The TradeSelect Toggle Switch by Bryant is a residential grade, three-way electrical switch designed for controlling lighting and electrical circuits in homes. It provides reliable on/off switching with a positive snap action mechanism, suitable for use by electrical distributors and lighting solutions providers. This switch is ideal for residential applications requiring three-way control, offering compatibility with standard wiring and mounting methods.

Specifications

• Application: Residential Toggle Switches
• Amperage Rating: 15A
• Voltage: 120V AC
• Number of Poles: Three Way
• Contact Rating: Per UL 20
• Operating Cycles: 10,000 Cycles
• Connection: Push and Side Wired
• Mounting: Screw Mount
• Action: Positive Snap
• Contact Configuration: Two Position
• Enclosure: None
• Insulation: None
• Width: 1.4 in
• Product Weight: 0.53 lbs
• Environmental Conditions: Indoor Dry unless protected by additional means
• Country of Origin: China
• Manufacturer: Bryant
• Manufacturer Part #: RS315I
• UPC: 883778100925
• Industry Standards: CSA Certified, UL Listed E3896
• Material: Tough thermoplastic base and cover
• Termination: Side Wire

Features

• Hi-visibility yellow base for easy installation
• Elongated strap for easier wall box mounting
• Tough thermoplastic with ultrasonically welded cover and base for durability
• Quiet snap action mechanism for reliable switching
• Suitable for residential wiring with push and side wire connections
