Description
Features
- Smooth indented face appearance
- Multiple-drive Slot/Phillips/Robertson head screws
- Tough thermoplastic ultrasonically welded cover and base
- Tamper Resistant- Self Grounding
Specifications
- Country of Origin: China
- Current / Amperage Rating: 20 A
- Width: 1.400 in
- Each - Width: 1.400 in
- Performance: Environmental - Operating temperature - -20°C to 60°C;Mechanical - Terminal - Terminal screws accepts up to #12 AWG, Push wire designed for #14 AWG solid copper wire only
- Amperage Rating: 20 A
- Application: Residential Receptacles
- Color: Gray
- Environmental Conditions: Indoor Dry Unless Protected By Additional Means
- NEMA Rating: 5-20R
- Number of Poles: 2-Pole
- Number of Wires: 3-Wire Grounding
- Phase: Single Phase
- Special Features: Tamper Resistant- Self Grounding
- Voltage Rating: 125 VAC
- Wattage: 2500
- Wire Size: #12 AWG to #10 AWG
- Voltage Rating Description: 125 VAC
- Connectivity: Side Wired
- Display Size: Standard Sized Product
- Nema Rating: 5-20R
- Number Of Poles: 2-Pole
- Number Of Wires: 3-Wire Grounding
- Class Code: A80
- Description - Invoice: RESI SGL RCPT, 20A 125V, TR, GY
- Freight Class Code: 06168002
- Harmonization Code: 8536698000
- Image Actual Or Representative: A
- MSDS Flag: No
- Sub Class Code: A80A805
- Material - Mounting Hardware: Screw Mounting
- Current Rating: 20 A
- Material: Thermoplastic
- Base Unit of Measure: EA
- BOX SIZE: 2.200x7.900x4.400 (in)
- Carton - Gross Weight per Pack: 1.2 lb.
- Carton - Number of Sub Packs: 10
- Carton - Pack Description: Carton
- Carton - SCC-14 Next Lower Level Sub Pack: 883778301971
- Carton - Total Units: 10 EA
- Case - Total Units: 100 EA
- Case Weight: 10.000 lb.
- Each - Pack Description: Each
- Lowest Level UOM: Each
Certifications
- EU RoHS Indicator: Yes
Downloads
Spec SheetCatalog Full Asset Reference
Catalog Page Asset Reference
Sales Drawing Asset Reference
Warranty Document Asset Reference
RR201GYTR AutoCAD Drawing
Tamper-Resistant Receptacles for Residential Applications
