tradeSELECT® Straight Blade Male Plug 30A Non-Grounding Polarized – Electrical Connector

This tradeSELECT® Straight Blade Male Plug is designed for residential range and dryer devices, providing a reliable connection for electrical distributors and lighting solutions requiring wire and cable components. It is a 3-pole, 3-wire non-grounding polarized plug suitable for indoor dry environments unless additional protection is applied. The plug supports amperage ratings of 30 or 50 amps and operates at 125/250 volts, making it compatible with NEMA 10-50P configurations.

Specifications

• Application: Residential Range and Dryer Devices
• Amperage Rating: 30 or 50 AMP
• Current: 50 amperes
• Voltage: 125/250V
• Number of Poles: 3-Pole
• Number of Wires: 3-Wire
• NEMA Rating: 10-50P
• Material: Composite
• Color: Black
• Width: 2.750 in
• Mounting: Cord Mounted
• Cord Type: All Portable
• Connection: Pressure Terminal Screws
• Product Weight: 0.3000 lbs
• Environmental Conditions: Indoor Dry unless protected by additional means
• Country of Origin: China
• Manufacturer: Hubbell Wiring Device-Kellems
• Manufacturer Part #: RR335P

Features

• Trade-select straight blade design for secure electrical connection
• Non-grounding polarized configuration ensures proper orientation
• Pressure terminal screws provide reliable wire termination
• Composite material housing for durability and electrical insulation
• Cord mounted for versatile installation on all portable cords
• Complies with NEMA 10-50P standard for compatibility with residential devices

Downloads & Links

• Catalog Full Asset Reference
• RR335P AutoCAD Drawing
• Sales Drawing Asset Reference
• Installation Manuals Asset Reference
• Catalog Page Asset Reference
• Spec Sheet
• Warranty Document Asset Reference
