Toggle, Specification Grade, Back and Side Wired
SKU: #139355
Part: #CSB120BRLV
UPC: 783585554785
Toggle, Specification Grade, Back and Side Wired
SKU: #139355
Part: #CSB120BRLV
UPC: 783585554785
Description
Toggle, Specification Grade, Back and Side Wired Switch
This toggle switch from Hubbell Wiring Device-Kellems is a specification grade, heavy-duty electrical component designed for low voltage applications. It operates at a maximum current of 5 amperes at 24V DC and is suitable for use in wiring and lighting control systems. The switch features back and side wiring options, making it compatible with various installation requirements. It is ideal for electrical distributors, lighting solutions providers, wire and cable specialists, and switchgear suppliers seeking reliable, specification-grade toggle switches.
Specifications
- Manufacturer: Hubbell Wiring Device-Kellems
- Manufacturer Part #: CSB120BRLV
- Color: Brown
- Amperage Rating: 5 A
- Operating Current: Maximum of 5A @ 24VDC
- Configuration: 3-Way
- Front Material: Thermoplastic
- Base Material: Thermoplastic
- Contacts: Silver Alloy
- Terminal Screws: Brass
- Mounting Bridge: Steel, Zinc Plated
- Terminal Accommodations: #14 AWG min. - #10 AWG max. solid or stranded copper wire only
- Operating Temperature: Max. continuous 75°C; Min. continuous -40°C without impact
- Width: 1.9 in
- Product Weight: 1.5 lbs
- Country of Origin: China
Features
- Maintained contact for reliable switching
- Thread cleaning captive mounting screw for secure installation
- Automatic self-grounding stainless steel staple for safety
- Back and side wired for flexible wiring options
