Toggle, Specification Grade, Back and Side Wired - Electrical Switch

This toggle switch by Hubbell Wiring Device-Kellems is a specification grade electrical component designed for low voltage applications. It supports a maximum operating current of 5 amperes at 24V DC, making it suitable for precise control in lighting solutions and wiring systems. The switch is back and side wired, facilitating flexible installation for electrical distributors and switchgear suppliers.

Specifications

• Manufacturer Part #: CSB120ILV
• Color: Ivory
• Amperage Rating: 5 A
• Configuration: 3-Way
• Operating Current: Maximum of 5A @ 24VDC
• Front Material: Thermoplastic
• Base Material: Thermoplastic
• Contacts Material: Silver Alloy
• Terminal Screws Material: Brass
• Mounting Bridge Material: Steel, Zinc Plated
• Terminal Accommodations: #14 AWG min. - #10 AWG max. solid or stranded copper wire only
• Operating Temperature: Max. continuous 75°C; Min. continuous -40°C without impact
• Width: 1.9 in
• Product Weight: 1.6 lbs
• Country of Origin: China

Features

• Maintained Contact
• Thread cleaning captive mounting screw
• Automatic self-grounding stainless steel staple
• Back and side wired for installation flexibility

Downloads & Links

• CSB120ILV AutoCAD Drawing
• Warranty Document Asset Reference
• Catalog Full Asset Reference
• Spec Sheet
• Catalog Page Asset Reference
